As golf has become one of the most popular recreational activities in the United States, compact electric golf push carts have also emerged as a new type of caddy for golfers, thanks to their lightweight and agile mobility. This installation and usage guide is designed to help golfers better understand and utilize golf carts, enabling them to fully enjoy an immersive and complete course experience.
In this article, we will use the NAVEE Bridie 3X electric golf cart as an example to provide a detailed, step-by-step installation tutorial and demonstrate the cart's self-following usage mode. Let's explore how to use this electric golf caddy.
Step 1: Unpack and check the installation parts
After receiving the golf cart, unpack it and check the delivery list to ensure that all parts are present and in good condition. This includes, but is not limited to: after-sales warranty card, instruction manual, push cart body, charger, remote control, cup holder, umbrella holder, front wheels, rear wheels, and anti-slip wheels.
Step 2: Install the rear wheels
After checking that all the necessary parts are present, take out the trolley body and the two rear wheels. Press and hold the red unlock button in the rear wheel hub, then align the square slots on both sides of the trolley rear wheel position and slowly push it in until it clicks into place. Release the red button. Repeat the same steps for the other wheel.
Step 3: Install the anti-slip wheels at the rear position
Find the square slot in the middle of the rear of the cart. As with the installation of the rear wheels, slowly push the anti-slip wheel assembly into the square slot until you hear a “click” sound to indicate successful installation.
Step 4: Unfolding the frame and handle
Find the red lever near the "NAVEE" logo. Press and hold this red switch to unlock the upper bag support. Then, pull the handle upward and adjust it to your desired position. Finally, push the upper handle forward until it clicks into place. The folding front wheel mount will automatically unfold during this process.
Step 5: Install the front wheels
After fully unfolding the golf cart, locate the black release button below the front wheel mounting frame and hold it down. Then align the silver protrusion on the front wheel with the slot on the frame, push the wheel into the slot until it clicks into place. Repeat the same steps for the other wheel.
After completing the above five steps, the basic frame of the golf cart is assembled. Next, install the included accessories and activate the relevant functions.
Step 6: Accessory Installation
Install the cup holder and umbrella holder
Locate the two recessed slots near the handle. Fit the protruding legs of the cup holder and umbrella holder into the slots and rotate clockwise to secure them in place.
Install the golf bag
Place the golf bag with its legs slightly tilted on the pocket support platform at the bottom of the cart, adjust the direction of the bag, and then use the high-elasticity rope attached to the bottom to secure it to the bottom of the cart. Similarly, unfasten the nylon hook-and-loop strap located in the middle of the column, wrap it around the middle and upper part of the golf bag, and fasten the buckle to secure the golf bag in place.
APP Connection
Turn on the golf cart. You'll see a flashing Bluetooth icon on the dashboard, indicating the cart is waiting to connect. Once your phone is successfully paired and the app is running, the Bluetooth icon on the dashboard will stabilize, indicating the phone is connected.
Remote Control Connection
Find the “+” button below the golf cart dashboard, hold it down while quickly pressing the red button on the right handle 5 times with your other hand. Then take out the remote control and quickly press the menu button 5 times. At this point, the WiFi icon on the display screen will start flashing, indicating that it has entered pairing mode. When the icon turns solid, it means that the remote control has been successfully connected.
Step 7: Unlocking multi-mode functions
Manual Push Mode
When the golf cart is powered on, press and hold the two assist buttons on the handlebar to move forward. Releasing the buttons will stop the golf cart from moving forward.
Auto-Follow Mode
Take out the remote control and press and hold the menu button for 3 seconds to enter automatic follow mode. The trolley will then emit a beep sound and begin searching for a signal. Once pairing is successful, the trolley will beep again and the indicator light on the dashboard will flash to notify you. Finally, place the remote control in your back pocket or belt, and the cart will automatically follow your direction of movement. Note that when pairing the remote control, you must aim the remote control downward toward the cart's power source to ensure a successful connection.
Conclusion
Anyway, assembly and activation of the electric golf cart are quick and easy. Just follow the steps above to enjoy the fun of the electric golf push cart. If you encounter any special issues during installation or have any unique installation tips, feel free to contact us via email or share them with us — after all, the joy of golf also lies in the process of exchanging ideas and solving problems together.
If you prefer a video tutorial on how to set up a golf cart, check out this video.
FAQ
Q: How to set up a golf bag for a push cart?
A: Most electric golf push carts come with two elastic straps or nylon buckle straps. First, secure the legs of the bag, then adjust the direction of the golf bag, usually with the outer bag facing backward, so it's easy to take things out of the bag. Finally, secure the bag with the straps. The NAVEE Birdie 3X golf push cart is equipped with a buckle strap and high-elasticity rope at the middle and bottom, effectively securing any style or brand of golf bag.
Q: Is the battery in an electric golf cart removable? How do I install or remove the battery?
A: Yes. Most electric golf carts have removable batteries. Installing and removing the battery on the NAVEE Birdie 3X is very simple. The process is as follows:
- Install the battery: Place the battery on the push cart and slide the battery connection switch to ON to connect the battery.
- Remove the battery: Slide the battery connection switch to OFF to disconnect the battery, then press and hold the release clip and grip the battery handle slots to lift the battery.
Q: How to quickly fold a foldable golf cart?
A: The process is simple, broken down into three specific steps:
- Step 1: Press and hold the red lever button and move the upper handle backward until it contacts the handlebars.
- Step 2: Fold the handlebars downward toward the vehicle until they contact the frame. Gently lift the front tire, and it will automatically retract.
- Step 3: Finally, press and hold the red lever and lean back until it clicks into place.
Q: Is an electric golf push cart worth it?
A: Of course. Electric golf carts can effectively improve a golfer's focus and stamina during a round, especially for those who prioritize comfort, performance, and a more enjoyable game. If you're hesitant about buying one, consider reading this article: Are Electric Push Carts Worth the Investment? A Golfer's Perspective
Q: Why won't my electric golf cart go forward or back?
A: First, check the cart's battery connections and the physical on/off button for proper function. If both are fine, then the issue may lie with more internal and complex components such as the engine or solenoid valve. Consulting the manufacturer or a professional for inspection and repair is a wise choice.
Q: How to quickly unfold a golf push cart?
- Step 1: Press the red button to unfold the upper handle and pull it upward until it is fully upright.
- Step 2: Continue pulling upward while holding the handle, and the folding wheels on both sides will automatically unfold.
If you want to adjust the handle position, continue pressing the red button and push it toward the handle. Once the handle is adjusted to your desired height, push the upper handle back until it is fully locked.
Q: Can you push an electric golf push cart?
A: Yes, most modern electric golf carts can continue to push even if the battery is depleted or the power is lost—thanks to a built-in flywheel or manual mode. For more information on how they work and selection guidelines, please read this article - Can You Push An Electric Golf Trolley?
